TECTUS® TE 640 3D A8 Energy Concealed Hinge

$630.49$745.13

SKU: TECTUS® TE 640 3D A8 Energy Concealed Hinge Categories: , , , ,

Features

  • For flush high performance commercial doors with claddings up to 8 mm (0.315″)
  • Energy hinges preserve all the technical and visual features of the TECTUS® hinge system
  • Easy to fit pluggable/unpluggable reverse-polarity-protected plug connection with integrated tension relief
  • 180° opening angle without pinching or damage during opening and closing
  • For doors up to 352 lbs with 2 hinges installed
  • EASILY adjustable in 3-Dimensions
  • Maintenance-free slide bearings
  • For wood, metal, or casing frame installation
  • Compatible with most designs for electric locks and fittings



Clear
7747FD379-3EF5-4DC3-9AB7-FB895BEEAAF3

TECTUS® TE 640 3D A8 Energy Concealed Hinge

(Energy cables not included)

Today’s modern and efficient buildings often require the ability to control and operate doors remotely. This requires the transfer of electrical power and information from door frames to door panels.

The TECTUS Energy Series provides a sophisticated way to utilize this technology when card readers, access and door control systems, electrified locks, monitoring systems, and multimedia components are installed. The cable with its 16 wires is completely concealed behind the hinge arms to prevent unauthorized tampering.

TECTUS enables the optimal integration of flush doors in straight line and flush surfaces for contemporary clean designs.

The SIMONSWERK TECTUS TE 640 3D A8 Energy concealed hinge is completely hidden for flush doors with wood, steel or aluminum doors and frames.

The three-dimensional adjustability and maintenance-free slide bearing technology of the TE 640 3D A8 Energy hinge system is for use with high-quality commercial doors.

For use with TE 640 3D A8 hinges

Features

  • For flush high performance commercial doors with claddings up to 8 mm (0.315″)
  • Energy hinges preserve all the technical and visual features of the TECTUS® hinge system
  • Easy to fit pluggable/unpluggable reverse-polarity-protected plug connection with integrated tension relief
  • 180° opening angle without pinching or damage during opening and closing
  • For doors up to 352 lbs with 2 hinges installed
  • EASILY adjustable in 3-Dimensions
  • Maintenance-free slide bearings
  • For wood, metal, or casing frame installation
  • Compatible with most designs for electric locks and fittings

Specifications

  • Minimum door thickness: 1-7/8″ not counting the 8mm (.315″) cladding
  • Height: 9.45″ [240mm]
  • Width: Frame & Leaf: 1.46″ [37mm]
  • Depth: Frame: 1.61″ [41mm] & Leaf: .71″ [43.5mm]
  • Cable supply: The hinge features a 16-wire integrated ribbon cable with plug connection to round cable at both ends. Cable set consists of 2 round cables both with reverse polarity-protected connecting socket for the special ribbon cables: one 3.0 m (118″) round cable for frame ; one 3.0 m (118″) round cable for door leaf. Cable tested to 1,000,000 cycles.
  • Max. Voltage: 60 V
  • Max. Current: 0.8 A

Available Finishes:

  • F1: Satin Chrome Look
  • SSL: Stainless Steel Look
  • Other finishes available. Contact us for minimum quantities and leadtimes: +1-888-636-1627

 More Information

*24mm router bit recommended with separate Routing Templates for Steps 1, 2 & 3 plus the Cable Plug Cavity Template for this Energy hinge.

*UL Listed: 20 minutes

*For Installation without cladding, use Coverplates for A8 Radius
  • For TE 640 3D A8 installation in steel frames you will need:
    One (1) TE 640 3D SZ Receiver per hinge
  • For TE 640 3D installation in casing frames you will need:
    One (1) TE 640 3D FZ/1 Fixing Plate per hinge
  • For installation in aluminum frames please contact us



This is a made to order, non-stock item. Orders are non-cancellable and non-returnable. Please review the details to ensure you are ordering the correct hardware.

Weight 0.8 kg
Dimensions 10 × 10 × 5 cm
Finish

Satin Chrome Look (F1), Stainless Steel Look (SSL)
