NORTON RIXSON Extended Pin Center Hung Pivot (PV-345)
$659.00 – $758.00
Enhance stability and accommodate taller doors with the NORTON RIXSON 345 Center Hung Top Pivot, featuring an optional design suitable for locations prone to building settling or for doors exceeding 8’6″ in height, offering a long pivot pin for a secure engagement with the top of the door, compatibility with center hung bottom pivots or floor closers, and a concealed appearance when the door is closed.
Finishes:
Share this:
Product Overview
Features
-
Long pivot pin engages in top of door 1-3/4″ (44mm)
-
Can be used with any center hung bottom pivot or floor closer whose pivot point is 2″ (50mm),or greater, from the edge of the door
-
Walking beam-type pivot – 1/2″ (13mm) diameter pivot pin
-
Completely concealed when door is closed
-
Furnished with wood and machine screws
-
Non-handed
-
Heavy-duty needle bearing
Benefits
-
Ideal for locations where there is a fear of dramatic building settling or for doors over 8’6″ (2491mm) in height
Specifications
-
Maximum Door Clearance: 3/8“
-
Minimum Door Clearance: 1/8“
| Weight | .5 lbs |
|---|---|
| Dimensions | 12 × 9 × 6 in |
| Finish: | US26D, 4E, 10BE, 314E, BSP, 315E, BPC, FBPC, WPC, WSP, RPC |
