NORTON RIXSON Center Hung Top Pivot (PV-340)

$202.00$255.00

SKU: N/A Categories: ,

NORTON RIXSON H340 Heavy-Duty

Experience superior functionality and seamless aesthetics with the NORTON RIXSON 340 Center Hung Top Pivot, the ideal choice for 28 Series floor closers. It features a concealed design when the door is closed.

Finish:
Clear
7747FD379-3EF5-4DC3-9AB7-FB895BEEAAF3

Product Overview

Features
  • Used with H28 Series floor closers

  • Can be used with any floor closer or pivot set with pivot point 2-3/4″ (70mm), or greater, from edge of the door

  • Walking beam-type pivot – 1/2″ diameter pivot pin with 3/4″ engagement

  • Heavy-duty needle bearing

  • Completely concealed when door is closed

  • Furnished with wood and machine screws

  • Non-handed



Specifications

  • Maximum Door Clearance: 1/4
  • Minimum Door Clearance: 1/8
Weight .350 lbs
Dimensions 12 × 9 × 6 in
Finish:

US26, US26D, 4E, 10BE, 314E, BSP, 315E, BPC, FBPC, WPC, WSP, RPC
