NORTON RIXSON 28 Floor Closers (FC-28, FC-PH28)

$2,051.00

SKU: N/A Categories: ,

NORTON RIXSON H340 Heavy-Duty

Rixson Heavy Duty Floor Closer

The NORTON RIXSON 28 Floor Closer is heavy-duty construction, including one-piece spindles, offers additional support to better handle heavier and/or high-traffic doors. It provides the best mechanical means to support and control a door with a concealed aesthetic that is also vandal resistant.

*FC-28 and FC-PH28 Closers include Closer Body, Cement Case and 26D Cover Plate. Selective hold opens (S) can be turned off

Clear
7747FD379-3EF5-4DC3-9AB7-FB895BEEAAF3

Product Overview

Features
  • Center hung

  • Single acting, handed

  • Separate and independent closing, latching, and backcheck valves

  • Built-in positive dead stop

  • Extended spindles available in 1/2″ increments up to 2″ longer than standard

  • Available with floor plate or threshold installation

  • Hold open options available

  • Includes FC-28ARM and floor plate



Benefits
  • Rustproof cement case



Specifications

  • Closer: FC-28, FC-PH28
  • Maximum Interior Door Width: 48
  • Case Material: Cycolac
  • Base Material: Cast iron
  • Maximum Door Weight: 350lbs.

Options

  • (90S) 90° Selective Hold open

  • (105S) 105° Selective Hold open

  • (PH) Factory set – 5 lbs. (Interior); 8-1/2 lbs. optional (Exterior) (available upon request)



Part #:

FC-28-90S-RH
FC-28-105S-RH
FC-28-90S-LH
FC-28-105S-LH
FC-PH28-90S-RH
FC-PH28-105S-RH
FC-PH28-90S-LH
FC-PH28-105S-LH

Weight 3 kg
Dimensions 12 × 9 × 6 cm
Type:

FC-28, FC-PH28

Hold Open:

90°, 105°

Spring:

N/A, 5 lb. Force

Handing:

Right Hand, Left Hand

Finish:

US26D, 10BE, 314E, BSP, 315E, BPC, FBPC, WPC, WSP, RPC
