Dorex 10010 Lever Manhattan


SKU: Dorex 10010 Lever Manhattan Categories: , , , Tag:

DorexDorex 10010 Lever Manhattan

Part of the Dorex Signature collection, this contemporary lever is ideal for residential applications.



Approximate finish simulation, for reference only


Dorex 10010 Lever Manhattan

  • 20 minute fire-rating available with listed fire-can*
  • For doors 138 to 134″ (35 to 45 mm) thick
  • Non-handed
  • Adjustable 238″ or 234″ (60 mm or 70 mm) backset
  • 5″ (127 mm) backset available
  • Stainless steel spring latch, available 4-Way or Universal type
  • Privacy function with auto-release
  • Full lip strike with 14″ (6.4 mm) radius corners
  • Entry model includes 5-pin cylinder, Weiser keyway with 2 keys

Keying services available. Other common keyways available.

(*)Fire-can must be ordered in conjuction with lockset

Weight 1 kg
Dimensions 25 × 25 × 25 cm

Passage, Privacy, Dummy, Pair


C15A Antique Nickel, C26D Satin Chrome, C32D Satin SS

Latch Option

Driven Latch, Square Corner
